Tri Tool 614RBL Thru 636RBL Clamshells - Manual (Page 54)

54
TRI TOOL INC.
92-0480 : Rev. 130916
Parts List, Model 614RBL Clamshell Sub-Assembly (P/N 02-2270)
Item Part
No. No. Description Qty
1. 19-0605 HOUSING, MAIN 1
32-0438 PIN, SPLITLINE, 1/2" DIA 4
33-0021 SCREW, CAP, #8-32 X 5/8" 4
33-0115 SCREW, CAP, 1/2-13 X 3 1/2" 2
2. 26-1351 BAR ASSY, ADJUSTABLE 4
3. 28-0057 SEAL, FELT 44”
(112 CM)
4. 28-0057 SEAL, FELT 66”
(168 CM)
5. 29-0290 BEARING, 90 ° VEE 16
6. 30-0415 RING, HOIST 2
7. 33-0089 SCREW, CAP, 7/16-14 X 1" 2
8. 33-0251 SCREW, CAP, 1/2-20 X 1" 2
9. 33-0483 SCREW, SET, #8-32 X 5/8", CUP PT 4
10. 33-1770 SCREW, SHLDR, 12 MM X 40 MM 16
11. 33-1792 JACKSCREW 2
12. 34-0271 WASHER, THRUST 16
13. 35-0374 NUT, ECCENTRIC, ADJUSTMENT 16
14. 39-0647 GEAR, HEADSTOCK 1
32-0236 PIN, SPLITLINE 4
33-0019 SCREW, CAP, #8-32 X 3/8" 4
33-0090 SCREW, CAP, 7/16-14 X 1 1/4" 2
15. 43-0400 COVER, DRIVE HOUSING SLOT 1
16. 48-0768 LOCK-BLOCK ASSY 2
17. 54-0375 FITTING, GREASE 1
18. 54-0304 PLUG, THREADED 4
NOT SHOWN:
05-1305 SHIPPING KIT, 600RBL SERIES 1
36-0003 WRENCH, L, 3/32” HEX 1
36-0010 WRENCH, L, 1/4” HEX 1
36-0011 WRENCH, L, 5/16” HEX 1
