Montigo 30FID Traditional - Manual (Page 33)

Page 33
XG00516- 150204
I-Series Indoor Gas Fireplace
Installation
Leveling the Unit
This unit has 4 leveling screws, 2 located inside the rear of the
firebox and 2 located at the bottom front of the Rear Faceplate.
Once the unit is in position, you can use a Phillips screw driver or
Slotted screw drivers to adjust each leveling screw as required.
2). Rear leveling screw adjustment (Linear burner version shown)
Figure 4 Sec.8
3). Front leveling Screw adjustment (Linear burner version shown)
Figure 5 Sec.8
1). Remove burner, see section on burner removal and install
4). Reinstall the burner.
