2-2

10-18-00

DaqBook / DaqBoard [ISA] / Daq PC-Card User’s Manual

Daq Data Acquisition Devices

Category

Device

Description

DaqBook

Portable Data Acquisition Modules
12-bit: DaqBook/100, /112, /120
16-bit: DaqBook/200, /216, /260

DaqBoard/2000 Series
(see note 1)

Plug-In Boards for PCI Bus-Slots
Six boards identified as /2000 through /2005

DaqBoard (ISA types)

Plug-In Boards for ISA Bus-Slots
12-bit: DaqBoard/100A, /112A
16-bit: DaqBoard/200A, /216A, /2000

Primary
Acquisition
Device

Daq PC-Card

Plug-In PCMCI Card
12-bit: Daq/112B
16-bit: Daq/216B

Analog Signal
Conditioning

Cards and modules used to condition Analog Signals
DBK/ 4, 7, 8, 9, 12, 13, 15, 17, 18, 19, 42, 43A, 44, 45, 50, 51, 52, 53, 54,
207, 207/CJC

Analog Output

Cards used to modify Analog Output Signals
DBK/ 2, 5

Digital I/O and Control

Cards and modules used to condition Digital I/O
DBK/ 20, 21, 23, 24, 25, 208

Expansion
Connections

Cards and modules used to expand the acquisition system.
DBK/ 1, 10, 11A, 35, 40, 41, 60, 200, 201, 202, 203, 204, 205, 206, 209

DBK Option
Cards and
Modules

Power Supply

DBKs: 30A, 32A, 33, 34; CDK10

Included Software

DaqView, DIAdem-View, Visual Basic extensions,
Application Programming Interface (API)

Software

Optional Software

DaqView/2000, DaqViewXL, DASYLab

Note 1: DaqBoard/2000 Series Boards are covered in the separate document,

DaqBoard/2000 Series

User’s Manual

, p/n1033-0901.
