Installation – CB System (Slug Mount) Install Track
System AA (CB) 9
4. Slide slugs into place with putty knife. Loosely install 4 mm x 20 mm screws.
Tip: Use putty knife to see if screws are loose enough to slide in groove.
Remember: Tracks may stick when reaching a spliced area on mast.
5. Loosen top screw. Slide top track up and position next 2.05 m (6'8 7/8") track.
Mast up: Tighten bottom screw to hold track.
6. Slide 19 mounting slugs and then the connector slug into mast groove.
Mast up: Tape in place.
One drop blue Loctite ® into each hole.
Loctite is a trademark of Henkel AG & Company KGaA
