Out the roll pin. see – Gasboy 9800 Atlas User Manual
Page 6
Installation of the Weatherproofing Kit
Page 6
MDE-4687 Weatherproofing Instructions for Atlas™ 9800 Units · August 2007
Figure 3: Removal of the Reset Handle
5
Remove the Nozzle Boot, Reset Handle Stops, and small black plastic plug. See
Figure 4: Nozzle Boot, Reset Handle Stops, and Small Black Plastic Plug
Remove these
Parts
Remove
Sheathing
Screws
Remove
Sheathing Screws
6
Remove the side sheathing screws (located inside the frame).
