SPECIFICATIONS
Composite and S-Video Component and RGBHV
Matrix Sizes* 8x4, 8x8, 12x8, 16x8, 16x16, 16x24, 24x24, 24x16, 8x32,
16x32, 24x32, 32x32, 32x8, 32x16 and 32x24
Connector Type Female BNC
Bandwidth 200MHz at -3dB 600MHz at -3dB
Fully Loaded @0.7Vpp (550 MHz @ -3dB on 8x4 models)
Flatness +/- .5 dB to 150MHz +/- 1.0dB to 300MHz
Gain Unity
Impedance 75 Ohm
Level .7V Nominal, 2V Max p-p
Sync RGBHV Only
Input Level .5V to 5V p-p 4V Nominal
Output Level TTL 2.4V into 75 Ohm Load
Impedance 75 Ohm
Polarity Same as Input
Cable Equalization N/A Available on EQ models
Audio Optional Optional
Input and Output # Matches Video I/O Configuration
Type Balanced Stereo
Connector 5 Position Pluggable Captive Screw Terminal
Frequency 20Hz to 20KHz
HD + Noise .05% at 1KHz at Max rated output
S/N Ratio >90dB
Impedance Input: 10K Ohm Output: 50 Ohm
Max Level Input and Output: +22dBm
Input Gain Switch 0/ +14 dB Switchable per Input
Input Trim Range +/-10 dB per Input
Output Volume Range -45 to +5 dB per Output
Audio Test Conditions Input- 1kHz tone @ 0 dBm. Output- 600 ohm load.
