Pathfi nder Matrix 31
LCD APPEARANCE SETUP
FRONT PANEL SETUP brings up the following screen:
ESCAPE
SELECT
FRONT PANEL SETUP
CONTRAST >
BACKLIGHT 100%
44
This screen allows adjustment of the CONTRAST and BACKLIGHT on the LCD display, .
CONTRAST deals with the difference in shade between the characters and the background, the
higher the number the bigger the difference.
DELAY TIME
DELAY TIME sets the RGB time delay for all RGB outputs. This is a global setting. RGB delay is
independently enabled or disabled via the output setup for any given RGB output.
The time range is .1 to 10.0 seconds with 00.0 indicating off. Each RGB output’s setup has the
ability to turn on or off RGB delay. The user will position the cursor using UP or DOWN buttons to
DELAY TIME and presses SELECT. The user then uses the UP and DOWN buttons to set the delay
time to the correct seconds, and tenths of seconds. Pressing the SELECT button then sets and stores
the delay time setting.
