2C.) Router Setup
The Router Setup is used to confi gure the Controller to control the Pathfi nder.
H
O
M
E
N
A
V
A
D
J
SYSTEM MENU
SW
V
E
R
DEST
SETUP
ROUTER
SETUP
D
I
A
G
R
E
S
E
T
NETWORK
SETUP
Modify Layers On Program
Off
Tally Mode
Off
INPUT
PATCH
Pressing the Router setup will bring up the ‘ROUTER SPECIFICATION’ screen which is shown
below:
Number of Inputs
Number of Outputs
Manufacturer
FSR
16
B
A
C
K
N
A
V
A
D
J
ROUTER SPECIFICATION
Number
1
8
Communication Type
ETHERNET
Router Type
ANALOG
COMM
SETUP
OUTPUT
PATCH
ADD
NEW
DELETE
ROUTER
[ FSR 01 ]
Name
Use the top rotary encoder to scroll down to the “Manufacturer” line and then use the bottom
rotary encoder to change the matrix manufacturer to FSR. As you scroll through the choices the
“Name” line will change automatically. After choosing “FSR”, scroll down using the top rotary
encoder to “Communication Type” and use the bottom rotary encoder to select "ETHERNET".
Once “FSR” and “ETHERNET” are selected, press the “COMM SETUP” button to go to the
“ETHERNET SETUP” screen, which is show below:
