Pathfi nder Matrix 29
The set time and date screen looks like this:
ESCAPE
SELECT
SET TIME/DATE
TIME
DATE
SAVE
01/01/01
01:00 am
The user presses the SELECT button, the display changes to the following screen:
ESCAPE
SELECT
SET TIME/DATE
TIME
DATE
SAVE
01/01/01
01:00 am 01
This signifi es that the user can now change the hour value; the user would use the UP and DOWN
buttons to change the hour setting. When the user is fi nished setting the hour the user will press the
SELECT button, which would change the display as follows:
ESCAPE
SELECT
SET TIME/DATE
TIME
DATE
SAVE
01/01/01
01:00 am 00
The user can set the current minutes month day and year in the same fashion as above by pressing
the SELECT button to scroll to the next desired fi eld and select a value using the UP and DOWN
buttons. The user may press ESCAPE at any point to return to the SYSTEM SETUP menu (settings
will not be saved).
When fi nished setting time and date, press the SAVE button. Pressing the SAVE button will save the
new settings. A "Saving time and date " message will appear briefl y on the LCD screen. The front
panel will then return to the system setup menu.
