50 Pathfi nder Matrix
2E.) Input Patch Setup
The INPUT SOURCE PATCH screen is used to defi ne the input sources available on the Pathfi nder
that are available to the Eagle 200s.
B
A
C
K
N
A
V
A
D
J
INPUT SOURCE PATCH
Source Number 1
DELETE
PATCH
FSR 01 Connection Type
1 Router Input E 200
1 Tally Number
ADD
PATCH
Press “ADD PATCH” to log change
This is a simple menu to work with, all you need to do is select a source number, then scroll down
to the router input that it’s connected to (normally source 1 goes to input 1, source 2 to input 2, etc.).
You then
press the ADD PATCH button to save the patch, and repeat for as many inputs you
are using on the Pathfi nder.
2F.) Output Setup
This menu is used to setup the Eagle 200’s output so that it matches the display devices used. This
menu is accessed from the home menu.
Color Space [ RGB ]
H
O
M
E
N
A
V
A
D
J
OUTPUT MENU
G
L
C
K
APPLY
FORMAT
SETTINGS
TEST
PATTERN
De Destination
1024x768 @ 59.94
Press APPLY FORMAT to select
the output resolution.
DVI EDID format can be adjusted
to match the output format in
the MISC > EDID menu.
Format
1
WIDE
SCREEN
