30 Pathfi nder Matrix
DUET TCPIP/IP SETUP
TCPIP/IP-DUET SETUP brings up a screen that looks like this.
ESCAPE
SELECT
AMX DUET >
DHCP
MC 00-50-C2-9F-40-A8
SAV
IP
DUET TCP/IP SETUP
XXX.XXX.XXX.XXX
DISABLED
DISABLED
AMX DUET
The user can enable the use of AMX Duet by selecting AMX DUET, using the up down buttons to
scroll and selecting ENABLE. When enabled, the Pathfi nder Matrix will send a UDP beacon that
can be discovered by an AMX DUET system.
DHCP and IP
When DHCP is enabled, the Pathfi nder Matrix will request an IP address from the DHCP server on
the local network it is connect to. When DHCP is DISABLED, a static IP address can be set. Scroll
to IP and press SELECT. Use the UP and DOWN buttons to change the numeric value of the fi rst
three digit group and press SELECT. The three indicator arrows will move to the next three digit
group to be set. Continue this procedure to set the desired static IP address.
Pressing SAV will save the settings above.
REMOTE PANELS SETUP under SYSTEM SETUP is used when a Pathfi nder Matrix Remote
Panel is connected to the Pathfi nder Matrix. Once selected, the user can choose "YES or "NO" to
activate or deactivate a Pathfi nder Matrix Remote Panel.
ESCAPE
SELECT
SYSTEM SETUP
TECH SUPPORT
SET TIME AND DATE
LCD SETUP
DELAY TIME SAV
REMOTE PANELS
TCP/IP - DUET SETUP
00.0
YES *
