DFI DT122-CR Manual - Manual (Page 44)

www.dfi .com
44
Chapter 7 BIOS Setup
Chapter 7
Select an Optimal Setting
for Super IO device
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Serial Port 4 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=228h; IRQ=11;
[Auto]
Serial Port 3 Configuration to Serial Port 6 Configuration
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
F81217 Second Super IO Configuration
This section is used to configure the serial port functions.
Set Parameters of Serial
Port 4 (COMB)
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
F81217 Second Super IO Confi guration
F81217 Second Super IO Chip
 Serial Port 3 Confi guration
 Serial Port 4 Confi guration
 Serial Port 5 Confi guration
 Serial Port 6 Confi guration
Advanced
F81217 Second IO
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
Serial Port
Enables or disables the serial port.
Change Settings
Selects the IO/IRQ setting of the I/O device.
F71879 Super IO Configuration
This section is used to configure the I/O functions supported by the onboard
Super I/O chip.
Restore AC Power Loss
help.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
F71879 Super IO Confi guration
F71879 Super IO Chip
 Restore AC Power Loss
Watchdog Timer
Super IO Watchingdog Timer
 Serial Port 1 Confi guration
 Serial Port 2 Confi guration
Advanced
Fintek F71879
[Power Off]
[Disabled]
10
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
ESC: Exit
Restore AC Power Loss
Off
When power returns after an AC power failure, the system’s power is off. You must press
the Power button to power-on the system.
On
When power returns after an AC power failure, the system will automatically power-on.
Last State
When power returns after an AC power failure, the system will return to the state where
you left off before power failure occurs. If the system’s power is off when AC power failure
occurs, it will remain off when power returns. If the system’s power is on when AC power
failure occurs, the system will power-on when power returns.
Watchdog Timer
Enable or disable Super I/O watchdog timer.
