RCS10 Technical Specifications Appendix A
Page 1-12
3 TXD_A Transmit Data A Input
4 TXD_B Transmit Data B Input
5 GND Signal Ground -------
6 DSR Data Set Ready Output
7 RTS Request to Send Input
8 CTS Clear to Send Output
9 NC No Connection ---------
J11 – Modem Status
Table 2-7.
J11- Modem Status 15-Pin ‘D’ Female
Pin No. Signal Name Signal Direction
1 Mod Fault - C MF-C No Dir.
2 Mod Fault - NC MF-NC No Dir.
3 Mod Fault - NO MF-NO No Dir.
4 Demod Fault - C DF-C No Dir.
5 Demod Fault - NC DF-NC No Dir.
6 Demod Fault - NO DF-NO No Dir.
7 Common Equipment Fault - C CEF-C No Dir.
8 Common Equipment Fault - NC CEF-NC No Dir.
9 Common Equipment Fault - NO CEF-NO No Dir.
10 Prompt - NO NC No Dir.
11 Prompt - NC NC No Dir.
12 Deferred - NO NC No Dir.
13 Deferred - NC NC No Dir.
14 Prompt C/AGC + AGC Out No
Dir./Output
15 Deferred C/AGC - GND No
Dir./Output
