The graphic data stream contains a graphic header record
followed by data streams for each row of dots in the image.
Syntax
{ G##,0,0,0,0
p
;...dot codes...
p
;...dot codes...
p
;...dot codes...
p
.
.
.
}
Field Contents
G##
Must begin with the letter "G" to identify
this as a graphic data stream.
The G is followed by a one or two digit
number to identify the graphic image.
Later you will use this number to insert the
graphic into a format.
Values: 0-99
NOTE: If this graphic is used in offline
batch entry, the printer assigns a
name of GPH## where ## is the
ID number assigned here.
ROW
Enter 0.
COLUMN
Enter 0.
LINES
Enter 0.
DOTS
Enter 0.
9400 Series Programmer’s Manual
5-4
