DENSITY
One digit for the bar code density for
Interleaved 2 of 5, Code 128, MSI, Code
39, and UPC/EAN barcodes.
Values: 1-5
Some bar codes do not support all 5
values.
For the actual densities for these values,
see "Quick References."
BFONT
One digit indicating which bar code font to
use.
Values:
1 UPC-A
2 UPC-E
3 Interleaved 2 of 5
4 Code 39
5 Codabar
6 EAN-8
7 EAN-13
8 Code 128
9 MSI
10 UPC/EAN+2
11 UPC/EAN+5
F-ROT
Field rotation. The direction of the field
with respect to the supply.
Values:
0 = top of field toward top of supply
1 = top of field toward left of supply
2 = top of field toward bottom of supply
3 = top of field toward right of supply
HEIGHT
One to four digits for the bar code height
in tenths of millimeters. The value should
be less than the length or width of the
supply.
Values: 50-2032 (5.1 to 203.2 mm or
0.2 to 8.0 inches)
