The cable interface for PC null modems is shown below.

9400

PC

FG

1

1

FG

TD

2

2

TD

RD

3

3

RD

RTS

4

4

RTS

CTS

5

5

CTS

DSR

6

6

DSR

CD

8

8

CD

DTR 20

20 DTR

SG

7

7

SG

9400 Series Programmer’s Manual

3-6
