Format Data
Format data contains the following.
•
Format identification number and name
•
Supply size
•
Online field definitions for text, bar code, line and
graphic fields
The following offline format elements are not supported online.
•
Merged fields
•
Sub-fields
•
Time or date fields
•
User-defined check digits
•
Fixed characters
•
Alphanumeric distinction
•
Fixed or variable length
•
Price fields
You must supply these elements if you need them in your
program.
The message structure used to transmit online format data is
shown below, followed by an example.
{ FORMAT ID, LENGTH, WIDTH; FORMAT_NAME
p
TEXT FIELD, INCREMENT FLAG, INCREMENT VALUE, ROW,
COLUMN, MULTIPLE, TEXT FONT,
CHARACTER ROTATION, FIELD ROTATION, COLOR
p
BARCODE FIELD, INCREMENT FLAG, INCREMENT VALUE,
ROW, COLUMN, DENSITY,BAR CODE FONT,
FIELD ROTATION, HEIGHT, READABLE CHARACTERS
p
LINE FIELD, ROW, COLUMN, DIRECTION, STOP,
THICKNESS
p
GRAPHIC FIELD, ROW, COLUMN
p
.
.
}
