MAG
One to two digits as the magnification
factor for the font of text fields.
Values: 1 - 10
NOTE: Font magnifications creating
greater than 30% black print on a
format may result in lower print
quality.
TFONT
One digit as the font for the TEXT field.
See "Quick References" for font samples.
Values:
1 Standard
2 Reduced
3 Bold
5 OCR-A
6 UPC HR1
7 UPC HR2
C-ROT
Character rotation. The direction
characters point with respect to the field.
Values:
0 = tops of characters toward top of field
1 = tops of characters toward left of field
F-ROT
Field rotation. The direction of the field
with respect to the supply.
Values:
0 = top of field toward top of supply
1 = top of field toward left of supply
2 = top of field toward bottom of supply
3 = top of field toward right of supply
COLOR
One character to define the color of a text
field.
Values:
B = Black characters (42H)
W = White characters on black (57H)
