THICKNESS
One or two digits for the line thickness in
dots.
9425 1 dot = 1/192 inch
9445 1 dot = 1/192 inch
9465 1 dot = 1/192 inch (horizontal line)
1 dot = 1/264 inch (vertical line)
9474 1 dot = 1/192 inch
Values: 1-15
NOTE: Horizontal and vertical line widths
on the 9465 printer do not match
exactly. To choose compatible
horizontal and vertical line widths,
refer to the Line Width table in
"Quick References."
Example
L22,400,100,1,190,5
p
This line field has the following attributes:
•
Line field number is L22.
•
Line begins 40 millimeters from the bottom of the print
area.
•
Line begins 10 millimeters from the left edge of the print
area.
•
This is a horizontal line (direction = 1).
•
The line ends 19 millimeters from the left edge of the
supply.
•
The line is 5 dots thick.
Syntax Checklist
•
Make sure this record is preceded by a format header
record.
•
Make sure the first parameter (field number) begins
with L.
M
essag
e S
tru
ct
u
res
4. Message Structures
4-23
