PCIE-8120 Hardware Description
PCIE-8120 Installation and Use (6806800R89C)
74
B.9.2.6
Debug LED
The card provides 8 Debug LEDs to the CPLD to indicate the power-up status and generic fault
conditions. The LEDs 0-7 are located on the top component side of the card near the PCI
Express connector, oriented from left to right. In default run state, all LED are off. For LED error
codes see the table below:
Table B-2 Sensor alert default values
Sensor type
Minor
Major
Critical
Inlet Temp
>50°C
>55°C
>60°C
Outlet Temp
>55°C
>70°C
>80°C ***
Delta Temp
<5°C *
>15°C
> 0°C
Card Power 12 OCT
60W@12V
65W@12V
70W@12V
Supply Bus voltage
< 11.5V
< 10 V
< 9V
Supply Bus current 4 OCT
1.8A **
2.1A **
2.5A **
Supply Bus current 12 OCT
>5 Amp
>6.5 Amp
>7 Amp
Card Power 4 OCT
22W@12V
26W@12V
30W@12V
Card Power 12 OCT -N****
60W@12V
78W@12V
84W@12V
* A low delta temperature reflects poor system cooling capability.
** It is not recommended to use current readings for alarms as they depend on varying
voltage. Use card power readings instead.
*** The PCIE-8120 temperature sensors are pre-configured to shutdown the card when
either sensors reach 80 °C. The system can restart when the temperature falls below 75 °C.
**** The higher sensor readings for -N version reflect exceptional operating conditions per
NEBS requirement.
Table B-3 LED Error Code
LED NUMBER
DESCRIPTION
2
1
0
Off
Off
Off
Enable state-12V stable
