PCIE-8120 External Connectors
PCIE-8120 Installation and Use (6806800R89C) 52
A.3 J1/J2 External Ethernet Connector s/w status
LEDs (not available on -N versions)
Two 10/100/1000BASE-T IEEE802.3 compliant Ethernet ports are available on the PCIE-8120
via RJ45 style connectors (except -N versions). They are provided through two Transceiver
devices (PHY) connected to the MSW:
LED0 : YELLOW: LINK
LED1 : GREEN : ACTIVE
19 PETp1 Transmitter differential pair,
Lane 1 RSVD Reserved
20 PETn1 GND Ground
21 GND Ground PERp1 Receiver differential pair,
Lane 1
22 GND Ground PERn1
23 PETp2 Transmitter differential pair,
Lane 2 GND Ground
24 PETn2 GND Ground
25 GND Ground PERp2 Receiver differential pair,
Lane 2
26 GND Ground PERn2
27 PETp3 Transmitter differential pair,
Lane 3 GND Ground
28 PETn3 GND Ground
29 GND Ground PERp3 Receiver differential pair,
Lane 3
30 RSVD Reserved PERn3
31 PRSNT2# Hot-Plug presence detect GND Ground
32 GND Ground RSVD Reserved
End of the x4 connector
Table A-1 PCIE-8120 Card Edge Connector Pin out (continued)
Pin
# Side B
Name Description Side A
Name Description
