Sorensen SF Series Configuration
Powering up in remote mode will result in the following operating conditions:
REMOTE MODE POWER-ON CONDITIONS
Condition Default
Current
Initial power–on current. Default value = OA. See
CAL:INIT:CURR
Soft Current Limit Model maximum current
Delay 0.5 seconds
Foldback Protection OFF
Output ON
Hold OFF
Unmask NONE
Service Request
Capability
OFF
2.2.2 Power-On GPIB Service Request (PON SRQ) Selection
Set the rear panel PON SRQ switch to ON to cause a GPIB service request to be sent to the
computer controller when the supply is turned on.
POWER-ON GPIB SERVICE REQUEST (PON SRQ) SWITCH
Switch Position Description
ON Power-On SRQ selected
OFF No Power-On SRQ selected
Refer to your specific GPIB controller card manual for further details on serial polling.
2.2.3
2.2.4
Shield Ground
Connects GPIB cable shield to chassis ground.
Address Selection
The SFA address selection is binary with switch A0 as the LSB and A4 as the MSB. The rear
panel switch illustration in Section 2.2 shows the address selection 00101 in binary (5 decimal).
The SFI address is selected and enabled from a list in the Remote menu. See SFI Operation
manual for more details on Remote menu, Navigation and Editing.
The address selection for a unit is the GPIB address of that device (1-30). SCPI reserves
channel 0 as the global channel to address all channels.
M550292-03 (Programming) 2-3
