KBF LQC (E5.3) 07/2014 page 90/114
We recommend taking out a maintenance agreement. Please consult BINDER Service:
BINDER telephone hotline:
+49 (0) 7462 2005 555
BINDER fax hotline: +49 (0) 7462 2005 93555
BINDER e-mail hotline: [email protected]
BINDER service hotline USA: +1 866 885 9794 or +1 631 224 4340 x3 (toll-free in the USA)
BINDER service hotline Asia Pacific: +852 390 705 04 or +852 390 705 03
BINDER service hotline Russia and CIS +7 495 988 15 16
BINDER Internet website http://www.binder-world.com
BINDER address BINDER GmbH, post office box 102, D-78502 Tuttlingen
International customers, please contact your local BINDER distributor.
18.2 Replacement of the fluorescent tubes
The average life expectancy of the fluorescent tubes is about 10,000 hours. We recommend replacing
the tubes every year in order to ensure full light intensity.
To replace the fluorescent tubes, unscrew and remove the clamping strips resting against the glass plate
(Allen screwdriver). Then lift the plate from the cassette. Rotate the tubes by 90° and pull them out of
their holders. When setting in the new tubes, observe the tube orientation (inscription, Figure 24). Fix the
glass plate screwing the clamping strips.
Figure 38: Dismounting a light cassette
Always replace all the fluorescent tubes of a light cassette together. Otherwise, homogeneity
of light intensity cannot be guaranteed.
18.3 Calibrating the light sensors and adjusting the controller display
The light sensors are supplied with a calibration certificate giving at least 2 measuring values with the
related measuring current values.
For recalibrating the light sensors, send the sensors to BINDER factory service.
If an independent reference measuring device is used to directly compare the light intensities,
it must bear the same spatial sensitivity characteristics (spherical) as the sensors of the
BINDER system (chap. 16.4).
