KBF LQC (E5.3) 07/2014
page 25/114
Do not install or operate the constant climate chamber KBF LQC in potentially explosive areas.
DANGER
Explosion hazard.
Danger of death.
∅
Do NOT operate the unit in potentially explosive areas.
KEEP explosive dust or air-solvent mixtures AWAY from the vicinity of the unit.
Having turned off the unit, you must close the tap of the water supply. Install the unit in a way that the
freshwater supply is easily accessible.
4. Installation and connections
4.1 Spacers for rear wall distance
Please fix both spacers with the delivered screws at the unit rear. This serves to ensure the prescribed
minimum distance to the rear wall of 100 mm / 3.94 in.
Figure 8: Spacer for rear wall distance
Figure 9: Rear KBF LQC with mounted spacers
