Technical Details
Operating Manual PSSu K F INC
1001688­EN­06 32
Mechanical data 312437
Dimensions
Height 128,9 mm
Width 30,0 mm
Depth 56,0 mm
Weight 90 g
The standards current on 2005­04 apply.
8.1 Safety characteristic data
Operating
mode EN ISO
13849­1:
2008
PL
EN ISO
13849­1:
2008
Category
EN IEC
62061
SIL CL
EN IEC
62061
PFH
D
[1/h]
IEC 61511
SIL
IEC 61511
PFD
EN ISO
13849­1:
2008
T
M
[year]
– PL e Cat. 4 SIL CL 3 3,34E­09 SIL 3 5,62E­06 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
INFORMATION
A safety function's SIL/PL values are not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
