Page 29: Status information
Operation
Operating Manual PSSu K F INC
1001688EN06
29
7.2.4
Display elements for sensor supply
The module has an LED for the status of the sensor's supply voltage.
U
p
U
p
LED
Meaning
Designa
tion
Colour
Status
Signal
U
p
No supply voltage
Green
Supply voltage present
7.3
Status information
The I/O data with status information is described in the chapter entitled "Function Descrip
tion", under "Input/output data".
