Technical details
Operating Manual PSSu H m F DPsafe SN SD
1002933­EN­02 36
PROFIBUS DP interface 312066
Maximum data length of the Profibus interface
Input 244 Byte
Output 244 Byte
Transmission rates 1,5 MBit/s, 12 MBit/s, 185,5 kBit/s, 19,2 kBit/s, 3
MBit/s, 45,45 kBit/s, 500 kBit/s, 6 MBit/s, 9,6 kBit/
s, 93,75 kBit/s
Connection 9­pin female D­Sub connector
Protocol DPV1, PROFIsafe V2.4
Operating modes AutoBaud, Freeze Mode, Set Slave Address, Sync
Mode
Certification PNO
Manufacturer’s ID 0CB0h
Cycle time (t_ExtCo) 2...300 000 ms
Cycle time (t_ExtCo) with PROFIsafe 4...32000 ms
Environmental data 312066
Climatic suitability EN 60068­2­1, EN 60068­2­14, EN 60068­2­2, EN
60068­2­30, EN 60068­2­78
Ambient temperature
Temperature range 0 ­ 60 °C
Storage temperature
Temperature range ­25 ­ 70 °C
Climatic suitability
In accordance with the standard EN 60068­2­78
Humidity 93 % r. h. at 40 °C
Condensation during operation Not permitted
EMC EN 61000­4­2, EN 61000­4­3, EN 61000­4­4, EN
61000­4­5, EN 61000­4­6, EN 61000­6­2, EN
61000­6­4
Vibration
In accordance with the standard EN 60068­2­6
Frequency 10,0 ­ 55,0 Hz
Amplitude 0,35 mm
Acceleration 1g
Shock stress
In accordance with the standard EN 60068­2­27
Acceleration 15g
Duration 11 ms
In accordance with the standard EN 60068­2­29
Acceleration 10g
Duration 16 ms
Max. operating height above sea level 2000 m
Airgap creepage
In accordance with the standard EN 60664­1
Overvoltage category II
Pollution degree 2
