Operation
Operating Manual PSSu H m F DPsafe SN SD
1002933EN02
29
8.2.7
SO
The "SO" LED indicates the state of PROFIsafe in accordance with the PROFIsafe specific
ation.
Colour
State
Meaning
No Fmodule is configured
or
An Fmodule is configured but it is neither in "Operator
Acknowledge Requested" nor "Safe Operation" state
Green
"Operator Acknowledgement" is requested by at least
one Fmodule (OA_C requested)
PROFIsafe communication is ok
