Operation
Operating Manual PSSu H m F DPsafe SN SD
1002933­EN­02 25
8.2.3 FS RUN
The "FS RUN" LED shows the status of the FS resource.
Colour State Meaning
­ ­ ­ FS resource has not been started or is in a STOP condi­
tion
Green Operating state "FS resource in RUN condition without er­
ror":
The FS resource tasks are running without fault.
The project is licensed.
Operating state: "FS resource in RUN condition with error":
­ Task in TERMINATED state or
­ Task in STOP state
At least one FS resource task is not running.
The project is licensed.
Orange Operating state "FS resource in RUN condition without er­
ror":
The FS resource tasks are running without fault.
The project is unlicensed.
Operating state: "FS resource in RUN condition with error":
­ Task in TERMINATED state or
­ Task in STOP state
At least one FS resource task is not running.
The project is unlicensed.
} Only one task is present on the FS resource.
