Technical details
Operating Manual PNOZ m ES CANopen
1002699­EN­03 22
Environmental data 772134
Airgap creepage
In accordance with the standard EN 61131­2
Overvoltage category II
Pollution degree 2
Rated insulation voltage 30 V
Protection type
In accordance with the standard EN 60529
Mounting area (e.g. control cabinet) IP54
Housing IP20
Terminals IP20
Mechanical data 772134
Mounting position Horizontal on top hat rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Material
Bottom PC
Front PC
Top PC
Conductor cross section with screw terminals
1 core flexible 0,25 ­ 2,50 mm², 24 ­ 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors
0,20 ­ 1,50 mm², 24 ­ 16 AWG
Torque setting with screw terminals 0,50 Nm
Connection type Spring­loaded terminal, screw terminal
Conductor cross section with spring­loaded terminals:
Flexible with/without crimp connector
0,20 ­ 2,50 mm², 24 ­ 12 AWG
Spring­loaded terminals: Terminal points per connec­
tion
2
Stripping length 9 mm
Dimensions
Height 101,4 mm
Width 22,5 mm
Depth 115,0 mm
Weight 95 g
The standards current on 2012­10 apply.
