42 RAID Controller Configuration
StorCase Technology, Inc. InfoStation 12-bay RAID User's Guide - Rev. C00
Starting the Monitor Utility
NOTES: Microsoft ® Windows ® 3.x and Windows ® NT™ 3.5x include a program called
Terminal which does not support ANSI color. If using either O/S, select VT-100
for terminal emulation or use a third-party software program such as Procomm
for Windows.
Microsoft
® Windows ® 95/98/NT/2000 includes a program called HyperTerminal
that supports ANSI color.
The Monitor Utility is implemented with a VT-100 or ANSI terminal connected through the DB9
port on the rear of the InfoStation chassis (Figure 9). This utility is embedded in the firmware;
software loading is not required unless for upgrade purposes.
To find HyperTerminal in Windows:
1. Click on Start (normally located at the bottom left of the Windows desktop)
2. Go to Programs
3. Go to Accessories
4. Go to HyperTerminal
Figure 9: DB9 Port Location
(SCSI-to-SATA version shown)
DB9
Connectors
VT-100/ANSI
Terminal
External
Modem
