InfoStation 12-bay RAID User's Guide - Rev. C00

StorCase Technology, Inc.

RAID Controller Configuration

25

SCSI

Interface

Wide

Fast

Ultra

Ultra2

SCSI-2

Wide SCSI

Disable

Ultra3

Ultra SCSI

Ultra Wide SCSI

Ultra2 SCSI

Ultra160 SCSI

Disable

Enable

Enable

Enable

Enable

[ENT]

[ENT]

[ENT]

[ENT]

[ENT]

[ENT]

Table 5: SCSI Set-Up

2.1.4 Speed

Select either Ultra3, Ultra2, Ultra, or Fast. Refer to Table 5 for settings.

2.1.5 Wide

Select either Enable (default) or Disable.

2.1.6 LUN Map

Select a LUN (0-15) and a corresponding slice to map to.

2.2 Secondary SCSI

This function enables the user to configure Secondary SCSI settings for use in multiple host

applications. Submenus are the same as 2.1 Primary SCSI.
