Introduction
3
InfoStation 12-Bay RAID User's Guide - C00
StorCase Technology, Inc.
The latest versions of the InfoMon utility program and User's Guide can be downloaded (free
of charge) from the StorCase web site (http://www.storcase.com). Contact StorCase for
further information. Refer to Appendix B for further information on optional InfoStation
accessories.
Using a modular approach supported by redundant features and hot swapping capabilities,
the InfoStation will provide continued data availability and allow for ease of maintenance and
minimal system down time.
The modular and scalable design of the InfoStation chassis also allows a variety of future
product upgrades to be offered. Upgrade modules (such as SNMP) are anticipated InfoStation
options.
This User's Guide describes the steps required for installing drive(s) into the InfoStation
external expansion chassis. This guide is intended to supplement documentation provided with
the host computer system, the operating system, and the drive(s) to be installed within the
InfoStation.
Features:
4U Rack Mount Chassis
One (1) 5.25" half-height bay (for canister-type SCSI device)
Supports dual SCSI Ultra160 host channels (SCSI-to-SATA version only)
Supports dual FC-ALs (FC-to-SATA version only)
Supports either twelve (12) Serial ATA or Ultra ATA/100 drives
Supports RAID levels 0, 1, 0+1, 3, 5
Supports 4 arrays and 16 LUNs
Corrosion-resistant steel construction
Two (2) 460W hot-swappable power supply modules
Two (2) hot-swappable variable-speed fan modules
Audible alarm
Status indicators at each bay
"Soft Start" circuitry
Web-based monitoring utility (InfoMon)
Online Capacity Expansion (OCE)
Hot spare and automatic drive rebuild
Fax/Pager notification
OS independent (no software or special drivers required)
RS-232 connector for system environmental monitoring, configuration, and control
Optional SNMP support
7-year limited warranty* and free 24/7 technical support
* 3-year limited warranty on RAID controller and Power & Cooling Modules
