20 RAID Controller Configuration
StorCase Technology, Inc. InfoStation 12-bay RAID User's Guide - Rev. C00
1 RAID Params
NOTE: Configuration changes made in the RAID Params menu must be saved and the
controller restarted before changes can take effect. Refer to section "5
NVRAM" for further information.
1 RAID Params 1.1 Array 1
1.1 Array 2*
1.1 Array 3*
1.1 Array 4*
1.7 Performance
1.1.1 Reconfigure
RAID
1.1.2 RAID Level
1.1.3 Disk
Number
1.1.4 Slice
Enable / Disable
Random /
Sequential
1.5 Stripe Size
1.6 Write Buffer
No / Yes
0 / 1 / 3 / 5 /
0+1 / None
Choices dependent
on RAID level
Create slices,
set slice size
128 / 64 / 32 /
16 / 8 sectors
* Submenus are the same as 1.1 Array 1
RAID Params Menu
1.1 Array 1
This function enables the user to configure/reconfigure Array 1.
