InfoStation 12-bay RAID User's Guide - Rev. C00 StorCase Technology, Inc.
RAID Controller Configuration 31
Terminal Port Menu
NOTE: The RAID controller's terminal port settings must match the settings of the re-
mote terminal on the host.
3.2 Terminal Port
This function enables the user to set the Baud Rate, Stop Bit, Data Bit, and Parity parameters
for the terminal port to match those of the host.
3.2.1 Baud Rate
Select either 2400, 4800, 9600, 14400, 19200, 28800, 38400, 57600, or 115200 (default).
3.2.2 Stop Bit
Select either 1 (default) or 2.
3.2.3 Data Bit
Select either 7 or 8 (default).
3.2.4 Parity
Select either None (default), Odd, or Even.
