Section 8 Using the OmniLink 5000 with LinkNet (Color OIT)
The OmniLink 5000 press automation control gains some powerful new capabilities when combined
with LinkNet. The OmniLink 5000 will work the same way it always has, but with a few additional
screens and softkeys.
8.1 Configuring the OmniLink 5000 for LinkNet (Color OIT)
Before the OmniLink can communicate with LinkNet, it must be assigned a machine number.
No two machines may have the same machine number or a machine number of 0!
Since LinkNet shares a single cable with all machines on the network, the machine number is used
by LinkNet to call out the machine it wants to “talk” to.
Stroke
Mode Single Stroke
Drive
Speed
Stroke
Speed
SPM
SPM
0
0 Order
Counter
PC STATUS
Counter OFF
P/C
CONFIG.
EXIT
0 0
Program/Run Switch
TOP
NAMES
RESTRICTED
PLS
TOP STOP
CALIBRATE
MACHINE
PARAMETERS
LUBE
OPERATOR
TERMINAL
Top Stop Calibration
Machine Parameters
Lubrication System
Operator Terminal
Restricted Programmable Limit Switch
Names and Messages
Exit Calibration
Figure 8.1: OmniLink Main Configuration Screen (Color Terminal)
• From the main screen
(the screen the
OmniLink powers up
in), select the “PRESS
CONTROL” softkey.
• With the Run/Prog
keyswitch in the
“Prog” position, press
the “CONFIG”
softkey. Note that this
softkey will not be
present unless the unit
is in program mode.
After entering the
access code, a screen
similar to Figure 8.1
should appear.
