8. Back Panel Interface
64
PLM+ SERIES Operation Manual rev 1.0.0
8.5. Power Inlet
8.5.1 Power Connector
7
A Neutrik NAC3 Series powerCON connector rated at 32 A is fitted to the rear of the PLM+ for AC mains input.
The power cable (AC cord) supplied with the PLM+ has the mating connector ready-fitted, but may require a mains
(AC) plug specific to your country to be fitted to the other end. The wiring an pinout details are shown in Table 8.2.
Table 8.16: powerCON Connector Wiring and Pinout
powerCON pin 230 V Version 115 V Version
L Brown Black
N Blue White
Green/Yellow Green
