83

Advanced Setup – Part 2

Advanced Setup – Part 2

Page

Default settings

Video Setup

4.

Video Setup

2

Component
In Assign

HDMI In
Assign

This assigns the component video input terminals for the
different input sources.

The HDMI input terminals are assigned for the different
input sources.
Select the HDMI audio signal playback method.

DVD

VDP

TV

1

67

3

Video Convert

This sets whether or not to use the video conversion
function.

ON

67

66, 67

DBS

VCR-1

VCR-2

V.AUX

1-RCA

NONE

2-RCA

3-RCA

NONE

NONE

NONE

Audio Delay

Set the audio delay timing to synchronize the sound and
video.

5

0 ms

68

On Screen
Display

This sets whether or not to display the on-screen display
that appears on the monitor screen when the controls on
the remote control unit or main unit are operated.

6

Function/Mode = ON, Master Volume = ON, Mode = Mode 1

68, 69

DVD

VDP

TV

DBS

VCR-1

VCR-2

V.AUX

NONE

NONE

NONE

NONE

NONE

NONE

NONE

4

HDMI Out
Setup

This sets whether or not to use the function for converting
analog video (composite video, S-Video or component
video) signals into HDMI signals.
When using this conversion function, set the color format
and video range of the signals output from the HDMI
terminal.

Convert = ON, Color Space = Y Cb Cr, RGB Mode = Normal

67, 68

Page

Default settings

Audio Input Setup

3. Audio Input Setup

63

Digital In
Assign

This assigns the digital input terminals for the
different input sources.

Input

source

Digital

Inputs

CD

DVD

VDP

TV

DBS

VCR-1

VCR-2

COAX 1 COAX 2

OPT 1

OFF

OPT 2

OPT 3

OFF

1

CDR /

TAPE

OPT 4

V.AUX

OPT 5

2

EXT.IN Setup

Set the Ext.In terminals playback method.

Surr.Sp = Surr.A, SW Level = +15dB

64

Input
Function Lev.

The playback level is corrected individually for the different
input sources.

TUNER PHONO

CD

CDR /

TAPE

DVD

VDP

TV

0 dB

0 dB

0 dB

0 dB

0 dB

0 dB

0 dB

3

VCR-2

0 dB

DBS

VCR-1

0 dB

0 dB

V.AUX

0 dB

4

Function
Rename

The names of the different input source can be changed as
desired and displayed on the display.

64

5

Tuner
Presets

FM stations are received automatically and
stored in the memory.

A1 ~ A8

B1 ~ B8

C1 ~ C8

D1 ~ D8

E1 ~ E8

87.5/89.1/98.1/107.9/90.1/90.1/90.1/90.1 MHz

520/600/1000/1400/1500/1710 kHz, 90.1/90.1 MHz

90.1 MHz

90.1 MHz

90.1 MHz

Auto
Preset
Memory

F1 ~ F8

G1 ~ G8

90.1 MHz

90.1 MHz

Preset channels that are not used often can be
skipped.

Preset
Skip

The preset channels can be given the names
you want.

Preset
Name

65

All preset channels = ON

65

65, 66

63, 64

TUNER PHONO

CD

CDR /

TAPE

DVD

VDP

TV

VCR-2

DBS

VCR-1

V.AUX
