36
Basic Operation Basic Operation
Dolby Pro Logic II x (Pro Logic II ) mode
STANDARD
CURSOR
SURROUND
PARAMETER
ENTER
1 Press the STANDARD button to select the “Dolby
Pro Logic II x” mode.
2 Play a program source
with the mark.
4 Press the CURSOR F F or G G button to select the
play mode.
Display
M O D E : P L x C
* S u r r P a r a m e t e r
M O D E : P L x M
* S u r r P a r a m e t e r
M O D E : P L x G
* S u r r P a r a m e t e r
(Pro Logic II x Cinema mode)
(Pro Logic II x Music mode)
(Pro Logic II x Game mode)
(Pro Logic II Cinema mode)
(Pro Logic II Music mode)
(Pro Logic II Game mode)
When the “SB CH OUT” parameter is set to “ON”. (Set
“Sp.Back” at the System Setup to “1spkr” or “2spkrs”).
The mode switches as shown below each time the
STANDARD button is pressed.
For operating instructions, refer to the manuals of the
respective components.
DTS NEO:6 DOLBY PL II x
3
Press the SURROUND PARAMETER button.
• The surround parameter menu is displayed.
5 Press the CURSOR D D or H H button to select the
various surround parameters.
Example: DOLBY PL II x music mode screen
When set with the on screen display using the remote
control unit while in the MUSIC mode, set the “
” mark
to “OPTIONS 0 ” pressing the CURSOR D D or H H button, then
press the CURSOR F F button.
Press the ENTER button to return to the previous screen.
ENTER
ON SCREEN
CURSOR
SURROUND
PARAMETER
STANDARD
• To play in the PL II x mode, set “Sp.Back” at the Speaker
Configuration setting to “1spkr” or “2spkrs”.
• To play in the PL II x mode, set “Surround Back” at the Power
Amp Assign setting.
When the “SB CH OUT” parameter is set to “OFF”. (Set
“Sp.Back” at the System Setup to “None”).
Display
M O D E : P L C
* S u r r P a r a m e t e r
M O D E : P L M
* S u r r P a r a m e t e r
M O D E : P L G
* S u r r P a r a m e t e r
* S u r r P a r a m e t e r
M O D E : D O L B Y P L
(Dolby Pro Logic mode)
