Denon AVR-3806 - Manual (Page 32)

27
Basic Operation Basic Operation
2 To choose the surround sound mode
Example: Dolby Digital
Press the STANDARD button.
For more information about the surround modes ( page
33, 34).
The volume can be adjusted within the range of –80 to +18
dB, in steps of 0.5 dB. However, when the channel level is
set (
page 42 or 77, 78), if the volume for any channel is
set at +0.5 dB or greater, the volume cannot be adjusted up
to 18 dB. (In this case the maximum volume adjustment
range is “18 dB — (Maximum value of channel level)”.)
Also, you may not be able to adjust the volume to the
maximum of 18 dB when internal volume compensation
control is activated due to the combination of the surround
mode and parameters, downmixing from multi-channel
audio signals into two channels, etc.
2 To select the Room EQ function
Press the ROOM EQ button.
For more information about the Room EQ function (
page 30).
SOURCE ROOM EQ
VOLUME FUNCTION
PHONES EXT.IN
STANDARD
INPUT MODE ANALOG
VIDEO SELECT
FUNCTION
ROOM EQ
MUTING
INPUT MODE
STANDARD
VOLUME
VIDEO SELECT
SPEAKER
Playing the input source
1 Select the input source to be played.
Example: CD
(Main unit) (Remote control unit)
To select the input source when ZONE2/3/REC SELECT,
VIDEO SELECT or TUNING PRESET is selected, press the
SOURCE button on the main unit then operate the FUNCTION
knob.
2
3
Start playback on the selected component.
For operating instructions, refer to the component’s manual.
Adjust the volume.
(Main unit) (Remote control unit)
M.VOL. -80.0dB
The volume level is displayed on the master volume level display.
