Denon AVR-3806 - Manual (Page 58)

53
Advanced Operation Advanced Operation
System call
3 Press the SYSTEM CALL button (1 to 3) you want
to register the system call.
4 Press the button you want to register.
• The IR segment blinks once after each key press.
The mode can be switched by pressing a MODE SELECTOR
button.
5 Repeat steps 4 to register the desired buttons.
Up to 32 signals each can be stored at the SYSTEM CALL 1
~ 3.
2 System call buttons
• Up to 32 signals each can be stored at the SYSTEM CALL 1 ~ 3
buttons.
• The System Call function can be used in the SYSTEM CALL
mode.
2 Storing system call signals
The accessorius remote control unit is equipped with “system
call” function allowing a series of remote control signals to be
transmitted by pressing a single button.
This function can be used for example to turn on the amplifier’s
power, select the input source, turn on the monitor TV’s power,
turn on the source component’s power and set the source to the
play mode, all at the touch of a single button.
1 Press and hole the SET UP button for at least
three seconds.
• The IR segment blinks twice.
1 Press and hold the SETUP button for at least
three seconds.
• The IR segment blinks twice.
2 Press the 9, 7, 8 button (9
→ → 77→ → 88))
to select
system call setting.
• The IR segment blinks twice.
2 Using the system call function
1 Press the AMP button to select SYSTEM CALL
mode.
2 Press the SYSTEM CALL button (1 to 3) at which
the system call signals have been stored.
• The stored signals are transmitted successively.
6 Press and hold the SETUP button for at least
three seconds to register the system call.
• The IR segment blinks twice.
NOTE:
• The remote control signals of the buttons pressed while
registering the system call signals are emitted, so be careful
not to operate the components accidentally (cover the
remote sensors, for example).
SYSTEM CALL
CHANNEL
NUMBER
SETUP
ON
MODE SELECTOR
IR segment
