34
Basic Operation Basic Operation
• In addition, screen information is displayed in the following
order when the ON SCREEN button is pressed repeatedly:
OSD-1 Audio input signal
OSD-2 Monitor information
OSD-3 Input/output
OSD-4 Auto surround mode
OSD-5 USER MODE 1
OSD-6 USER MODE 2
OSD-7 USER MODE 3
OSD-8~14 Tuner preset stations
NOTE:
• OSD-2:
The monitor’s resolution is displayed when an HDMI
monitor is connected to the AVR-3806.
• OSD-4:
This is displayed when the auto surround mode is set to
“ON” (
page 70) and the input mode is set to “AUTO”.
It is not displayed when the input mode is set to “ANALOG”
or “EXT. IN”.
FORMAT:
Displays the input signal’s number of channels.
“Number of front channels / Number of surround channels /
LFE on/off”
“SURROUND” is displayed for 2-channel signal sources
recorded in Dolby Surround.
OFFSET:
Displays the dialog normalization offset value.
FLAG:
Displays the special identification signal recorded in the input
signal (
page 35).
“MATRIX” is displayed when matrix processing is conducted
on the surround back channel, “DISCRETE” is displayed when
discrete processing is conducted.
Not displayed when no identification signal is recorded.
2 Dialogue Normalization
The dialogue normalization function is activated automatically
when playing Dolby Digital program sources.
Dialogue normalization is a basic function of Dolby Digital which
automatically normalizes the dialog level (standard level) of the
signals which are recorded at different levels for different
program sources, such as DVD, DTV and other future formats
that will use Dolby Digital.
When this function is activated, the following message appears
on the main unit’s display:
Display
O f f s e t - 4 d B
D i a l . N o r m
The number indicates the normalization level when the currently
playing program is normalized to the standard level.
2 Checking the input signal
The input signal can be checked by pressing the remote control
unit’s ON SCREEN button (
page 5).
SIGNAL:
Displays the type of signal (DTS, DOLBY DIGITAL, PCM, etc.).
fs:
Displays the input signal’s sampling frequency.
• Canceling night mode:
Press the NIGHT button again.
• The night mode only works when playing program sources
recorded in Dolby Digital.
• When the night mode is set to “ON”, the “D.COMP” surround
parameter can not be selected.
When listening at night or at lower volumes, the night mode
improves listenability.
Press the NIGHT button to enter the night mode.
• The NIGHT mode indicator lights.
Night mode
