58
Advanced Operation Advanced Operation
2 With “ZONE2 SOURCE” displayed, turn the
FUNCTION knob to select the source you want to
output appears on the display.
Outputting a program source to amplifier,
etc., in a ZONE2 room (ZONE2 SELECT mode)
• The signals of the source selected in the ZONE2 mode are also
output from the VCR-1, VCR-2 and CDR/TAPE recording output
terminals.
• Digital signals are not output from the ZONE2 and ZONE3 audio
output terminals.
• About the MULTI ZONE connections ( page 56, 57).
• Press the MUTING button to mute the audio temporarily.
The muting level is same as set with “Volume Control”.
• Cancelling muting mode:
Press the MUTING button again, or press the VOLUME button on
the remote control unit.
1 Press the ZONE2/3/REC SELECT button to
display the “ZONE2 SOURCE” on the display.
• The MULTI indicator lights.
The display switches as follows each time the button is
pressed.
3 Start playing the source to be output.
For operating instructions, refer to the manuals of the
respective components.
ZONE2/3/REC SERECT
FUNCTION
ZONE3 ZONE2
(RECOUT)
2 With “ZONE3 SOURCE” displayed, turn the
FUNCTION knob to select the source you want to
output appears on the display.
Outputting a program source to amplifier,
etc., in a ZONE3 room (ZONE3 SELECT mode)
1 Press the ZONE2/3/REC SELECT button to
display the “ZONE3 SOURCE” on the display.
3 Start playing the source to be output.
For operating instructions, refer to the manuals of the
respective components.
Remote control unit operations during multi-
source playback
1 Select the zone which you want to operate
pressing the
AMP button.
2 Press the ZONE2 (ZONE3) ON button to turn on
the zone power.
Press the OFF button to turn off the zone power.
3 Select the input source you wish to output.
When the input source is set to TUNER, the preset channel
can be selected using the CHANNEL + and – buttons on the
remote control unit.
4 The volume of the outputs of the different zones
can be adjusted with the
VOLUME button on the
remote control unit.
The output level can be controlled only if the zone volume
level is set “variable” at “Volume Control” in the “System
Setup Menu” (
page 72, 73).
DEFAULT VOLUME SETTING
ZONE2 : –40 dB
ZONE3 : –40 dB
The zone volume can be adjusted within the range of –70
to 18 dB, in steps of 1 dB.
The ZONE3 volume can be adjusted only when “ZONE3” is
selected at “Power Amp Assign” in the “System Setup
Menu” (
page 72).
AMP
ZONE2 ON/OFF
MUTING
CHANNEL VOLUME
ZONE3 ON/OFF
