42
Basic Operation Basic Operation
Press the CURSOR F F or G G button to set the level.
To increase the bass or treble:
The bass or treble sound can be increased up to +6 dB in
steps of 1 dB.
To decrease the bass or treble:
The bass or treble sound can be decreased down to –6 dB
in steps of 1 dB.
7
Press the ENTER button.
• The surround parameter menu screen reappears.
8 Press the ENTER or SURROUND PARAMETER
button to complete the setting.
4
6
Press the CURSOR G G button to select the “Tone
Defeat OFF”.
5
Press the CURSOR D D or H H button to select the
“Bass” or “Treble”.
2 Tone defeat mode
If you do not want the bass and treble to be adjusted, turn on the
tone defeat mode.
Press the TONE DEFEAT button to turn on the “Tone
Defeat” mode.
The signals do not pass through the bass and treble
adjustment circuits, providing higher quality sound.
Channel level
You can adjust the channel level either according to the playback
sources or to suit your tastes, as described below.
1
Press the ENTER button.
• The “Channel Vol.” screen is displayed.
2
Channels which is not used are not displayed.
Press the CURSOR D D , H H or ENTER button to
select the speaker.
The channel switches as shown below each time the ENTER
button is pressed.
3 Press the CURSOR F F or G G button to adjust the
level.
The adjustment range for the different channels is +12 dB
to –12 dB in step of 0.5 dB.
The sound from the subwoofer can be completely cut by
lowering the SW (subwoofer) setting one additional from
–12 dB (setting it to “OFF”).
FADER
SR
SBL SL SBR
FL C FR SW
Fader function
This function makes it possible to lower the volume of the front
channels (FL, C and FR) or the rear channels (SL, SR, SBL and
SBR) together. Use it for example to adjust the balance of the
sound from each position when multi-channel music sources are
played.
1
Press the ENTER button.
• The “Channel Vol.” screen is displayed.
2
Press the CURSOR D D , H H or ENTER button, then
select “Fader”.
The channel switches in the order shown below each time
the ENTER button is pressed.
FADER
SR
SBL SL SBR
FL C FR SW
• When the surround back speaker setting is set to “1spkr” for
“Speaker Configuration” ( page 75), this is set to “SB”.
• The channel whose channel level is adjusted lowest can be
faded to –12 dB using the fader function.
• If the channel levels are adjusted separately after adjusting the
fader, the fader adjustment values are cleared, so adjust the
fader again.
3 Press the CURSOR F F button to reduce the
volume of the front channels, the CURSOR G G
button to reduce the volume of the rear channels.
Example: When “FRONT” is selected
The fader function does not affect the subwoofer channel
