MATRIX 400™ REFERENCE MANUAL
78
5
Matrix 400™ EXTERNAL TRIGGER Vext 30 Vdc max.
A
B
Signal
V
V
CC
~
~
+ -
I1A
I1B
Figure 92 - External Trigger NPN Using External Power
Pin Name Function
A Vdc Power Supply input voltage +
D I2A Input 2 A (polarity insensitive)
E I2B Input 2 B (polarity insensitive)
L GND Power Supply input voltage -
INPUT 2 CONNECTIONS USING MATRIX 400™ POWER
INPUT DEVICE Matrix 400™
D
E
A
L
Ground
V
Signal
V
CC ~
~
+ -
Vdc
GND
I2A
I2B
Figure 93 - Input PNP Using Matrix 400™ Power
INPUT DEVICE Matrix 400™
Signal
D
E
A
L
Ground
V
V
CC ~
~
+ -
Vdc
GND
I2A
I2B
Figure 94 - Input NPN Using Matrix 400™ Power
