MATRIX 400™ REFERENCE MANUAL

Setup

5. Enter the Setup function by pressing and holding the

X-PRESS™ push button until the Setup LED is on.

6. Release the button to enter the Setup function. The

Setup LED will blink until the procedure is
completed.

The Setup procedure ends when the Image
Acquisition parameters are successfully saved in the
reader memory, the Setup LED will remain on
continuously and Matrix 400™ emits 3 high pitched
beeps.

If the calibration cannot be reached after a timeout of
about 5 (five) seconds Matrix 400™ will exit without
saving the parameters to memory, the Setup LED will
not remain on continuously but it will just stop
blinking. In this case Matrix 400™ emits a long low
pitched beep.

7. Exit the Setup function by pressing the X-PRESS™

push button once.

READY

green

yellow

red

SETUP

FOCUS

TEST

LEARN

GOOD

TRIGGER

COM

STATUS

Figure 10 – X-PRESS™ Interface:

Setup Function

Learn

8. Enter the Learn function by pressing and holding the

X-PRESS™ push button until the Learn LED is on.

9. Release the button to enter the Learn function. The

Learn LED will blink until the procedure is
completed.

The Learn procedure ends when the Image Density
value is successfully saved in the reader memory,
the Learn LED will remain on continuously, the
Green Spot is activated and Matrix 400™ emits 3
high pitched beeps.

If the calibration cannot be reached after a timeout of
about 3 (three) minutes Matrix 400™ will exit without
saving the parameters to memory, the Learn LED will
not remain on continuously but it will just stop
blinking. In this case Matrix 400™ emits a long low
pitched beep.

10. Exit the Setup function by pressing the X-PRESS™
