GENERAL VIEW
Matrix 400™
Figure A
1
2
3
4
9
8
7
Device Class Label
Mounting Holes (12)
Lens Cover
Lens
(separate accessory)
"POWER ON" LED
Power - Serial Interfaces - I/O Connector
Ethernet Connector
(Ethernet Models Only)
6
HMI X-PRESS™ Interface
5 Internal Illuminator
(separate accessory)
Ethernet Connection LED
(Ethernet Models Only)
10
7
1
3
4
5
2
6
8
9
10
2
2
