RAPID CONFIGURATION

3

1

CBX100/CBX500 Pinout for Matrix 400™


The table below gives the pinout of the CBX100/CBX500 terminal block connectors. Use this
pinout when the Matrix 400™ reader is connected by means of the CBX100/CBX500:

CBX100/500 Terminal Block Connectors

Input Power

Outputs

Vdc

Power Supply Input Voltage +

+V

Power Source - Outputs

GND

Power Supply Input Voltage -

-V

Power Reference - Outputs

Earth

Protection Earth Ground

O1+

Output 1 +

O1-

Output 1 -

Inputs

O2+

Output 2 +

+V

Power Source – External Trigger

O2-

Output 2 -

I1A

External Trigger A

(polarity insensitive)

Auxiliary Interface

I1B

External Trigger B

(polarity insensitive)

TX

Auxiliary Interface TX

-V

Power Reference – External Trigger

RX

Auxiliary Interface RX

+V

Power Source – Inputs

SGND

Auxiliary Interface Reference

I2A

Input 2 A

(polarity insensitive)

ID-NET™

I2B

Input 2 B

(polarity insensitive)

REF

Network

Reference

-V

Power Reference – Inputs

ID+

ID-NET™ network +

Shield

ID-

ID-NET™ network -

Shield Network Cable Shield

Main Interface

RS232

RS485 Full-Duplex

RS485 Half-Duplex

TX

TX+

RTX+

RTS

TX-

RTX-

RX

*RX+

CTS

*RX-

SGND

SGND

SGND


* Do not leave floating, see par. 4.2.2 for connection details.

CAUTION

Do not connect GND, SGND and REF to different (external) ground
references. GND, SGND and REF are internally connected through filtering
circuitry which can be permanently damaged if subjected to voltage drops
over 0.8 Vdc.
