Page 30
10. Other functions and settings
10.1 Switch ( SW2 ) function setting
You can select the navigation mode which control by SW2.The navigation of FY-41AP
show in the table,we can just select two modes for SW2 at the same time .
SW2 Mode Function Remark
Null SW-2 Deactivated
SW-2 set to NULL, Flying mode is controlled by
SW-1.
Go Home Auto Return To Launch
On activation, plane will automatically return to
launch (RTL) point.
Line
Fixed altitude & Heading lock
flight Mode
With no controlling input from the pilot, the
plane will automatically lock current heading &
maintain altitude.
Circle Auto Circling Mode (ACM)
Automatically fly, circling a fixed point. Centre is
at point of ACM activation.
If you upgrade the firmware to V1.16 or above version ,you need to set the SW2
functions by using ―FYGCS5.11 for FY41AP and Dos‖ software.After FY-41AP connect to
the GCS software successfully , you can select ―Menu->Autopilot Setting->RC Setting‖ to
finish the switch mode setting.
10.2 RC Max Distance Setting
The RC Max Distance Setting will not allow the plane to fly beyond the distance you
have set. Upon reaching this distance, the FY41AP will automatically engage RTL and fly
back to you.
