Page 12
7.5 Remote control setting: SW1&SW2
FY-41AP needs remote control and receiver with at least 6 channels, including 4
normal channels for AIL,ELE,THR,RUD, and two for SW1,SW2 to control flying mode.
You need to choose normal fixed wing plane mode canceling all mix control modes,
meanwhile setting CH5,CH6 to two three-switch.
FY-41AP need two three-switch to control flying mode:SW1 for deactivated mode,
stable mode, 3D mode; SW2 for return to home and fixed
attitude and head locking mode (default mode),circle, and
path flight mode(need set).
After setting the Switch, you can double check by
monitoring the indicator light on the module against
selected flying mode. Detail see the indicator light manual.
SW1&SW2 default set:
NOTE: SW-2 has priority over SW-1. Only when SW-2 is in the ‗Null‘ Mode can SW-1
work. Therefore ‗Null‘ should be one of the options for SW-2, otherwise SW-1 will not
work.
7.6 Gyroscope Reset
If the following conditions occur, the FY-41AP initialization is recommended:
1. The device has not been used for a long time.
2. There is a change in environmental temperature of over 30 degrees since last
flight.
3. The purple LED flashes continuously even when the FY-41AP remains
stationary and you never activate the motor.(When you in non navigation mode,
which means SW2 is ―NULL‖.
Note: For the better flight, we suggest you to do the gyro reset before each flight.
There are three way to realize the gyro reset. (The FY-41AP must keep stationary
during the gyro reset procedure)
SW1 SW2
Deactivated RTL
Stable NULL
3D ADH
